Brand Name : | HENGFENGYOU |
Model Number : | GCK |
Certification : | ISO IEC CB COC KEMA SNI SABS CCC |
Price : | 200-20000/piece |
Payment Terms : | LC T/T |
Supply Ability : | 5000 piece/year |
Delivery Time : | 30 days |
GCK low voltage electrical indoor switchgear
Features
GCK low voltage extractable switchgear is a combined low-voltage switchgear assembled by a standard
module, which is divided into power center distance, motor control center distance and power factor automatic
compensation cabinet. This switchgear meets the standards of IEC439-1, GB7251 and so on
Rated Insulated Voltage | AC660V , AV1000V |
Rated Working Voltage | AC380V , AC660V |
Rated Frequency | 50Hz |
Horizontal busbar rated current | 1250-4000A |
Vertical busbar rated current | 1000A |
Feeder circuit maximum current | 2500A |
Drawer circuit Maximum current | 630A |
Control motor maximum capacity | 320KW |
Horizontal busbar peak withstand current(0.1 S) | 63KA,105KA,176KA |
Horizontal busbar peak withstand current(1 S) | 30KA,50KA,80KA,100KA |
Vertical busbar peak withstand current(0.1 S) | 63KA,105KA |
Vertical busbar peak withstand current(1 S) | 30KA,50KA |
Rated working frequency withstand voltage(1 min) | 2500A |
Secondary frequency withstand voltage(1 min) | 2500A |
Dimension size ( width*deep*height) mm | 600(800/1000)*800(1000)*2200 |
![]() |
