    Electric 50kva 100kva Oil Immersed Transformer Three Phase Copper Winding

    Ask Lasest Price
    Brand Name : HENGFENGYOU
    Model Number : S-11
    Certification : ISO IEC CB COC KEMA SNI SABS CCC
    Price : 200-200000/piece
    Payment Terms : LC T/T
    Supply Ability : 5000 pieces/year
    Delivery Time : 15 DAYS
    • Product Details
    • Company Profile

    Electric 50kva 100kva Oil Immersed Transformer Three Phase Copper Winding

    ONAN 50kva 100kva transformer 400kva 1500kva 2500kva transformer


    Production Overview

    1. A multilayer cylinder structure is used for all high voltage windings in order to improve the voltage

    impulse distribution of winding.

    2. For the capacity range of medium voltage windings is from 30kVA to 2000kVA, the cylinder type

    or spiral structure is used to ensure the high mechanical strength, ampere lure distribution and

    excellent short-circuits proof performance.

    3. The securing structure is set in the transformer body, which is used for ensuring that no

    displacement will occur during the transportation;meanwhile, the turnbuckles are mounted in

    fasteners, which is for assuring that fasteners will not be loose during the long term operation.

    4. Corrugated tanks are used in the transformer for replacing the conservator. The tank enclosure

    and rim are completely sealed by welding or bolting up, which prolongs the service life of

    transformer oil.

    5. The transformer surface are painted with primer and finish coats after degreasing derusting, and

    phosphorizing; which can meet the special operation requirements in metallurgic and

    petrochemical industries, as well as, in moist and dirty places.

    6. The press relief valves, signal thermometers, and gas relays are equipped in the oil tank of

    hermetically sealed transformer in order to the standard requirements for safe operation. The

    transformers are attractive and competitive due to the compact shape, excellent and design,

    maintenance-free.



    Main Technical Parameters for 10KV level S9-M/S10-M/S11- M Series three-phase full-sealed non-excitaiton-tap-changing distribbution transformer
    Rated
    Power
    (kva)
    High
    Voltage
    (kv)
    H.V.Tap
    range
    Low
    Voltage
    (kv)
    Connection
    symbol
    Short
    Circuit
    Impendence
    (%)
    No-load loss(W)On-load loss(W)No load
    current
    (%)
    S9S10S11S9S10S11
    306
    6.3
    10
    10.5
    11
    ±5%
    ±2x2.5%
    0.4Dyn11
    Yyn0
    41301101006006006002.1
    501701501308708708702
    632001801501040104010401.9
    802502001801250125012501.8
    1002902302001500150015001.6
    1253402702401800180018001.5
    1604003102802200220022001.4
    2004803803402600260026001.2
    2505604604003050305030501.2
    3156705404803650365036501.1
    4008006505704300430043001
    5009607806805150515051501
    6304.512009208106200620062000.9
    800140011209807500750075000.8
    10001700132011501030010300103000.7
    12501950156013601200012000120000.6
    16002400188016401450014500145000.6
    200052830227019401714017140171400.6
    25003350269023002026020260202600.5
