110kv Series Oil Immersed Type Transformer, Frequency 50/60Hz , Copper Material

Ask Lasest Price
Brand Name :	HENGFENGYOU
Model Number :	110kv
Certification :	ISO IEC CB COC KEMA SNI SABS CCC
Payment Terms :	LC T/T
Supply Ability :	5000 pieces/year
Delivery Time :	15 DAYS
Price :	500-30000

Add to Cart

Product Details
Company Profile

110kv Series Oil Immersed Type Transformer, Frequency 50/60Hz , Copper Material

110kv Series Power Transformer ,Oil Immersed, on-Load Regulation Transformer

Product features

1, Product Range:15kVA-10000kVA, up to 44kV
2, System voltage: max. 36 kVA 200 BIL
3, Coolers: corrugated wall or radiator
4, Oil preservation: hermetically sealed or conservator/free breathing
5, Tap changer: off-circuit or on-load
6, Cooling medium: mineral oil, Midel
7, Steel type core clamping system
8, High voltage (HV) multilayer winding
9, Low voltage (LV) foil winding or layer winding
10, Winding materials aluminium or copper
11, High temperature class transformers
12, Low noise solution
13, Efficient transformers with reduced losses
14, Liquid-filled
15, Used in special conditions
16, Sophisticated facilities
17, Usage of wooden case
18, 3D package for drawings
19, Special test like Zero Sequence Impendence test
20, Cooling: ONAN, ONAN/ONAF, KFAF, KFW

Rated capacity (kVA)	Voltagecombination			Conn-ectedgrouplabel	No-load loss (W)	Loadloss (75"C)(W)	No-load current(%)	Impedance voltage(%)	Exteriorsize (Lxwxh)	Totalweight (kg)
Rated capacity (kVA)	High voltage(kV)	tap range	Low Voltage(kV)	Conn-ectedgrouplabel	No-load loss (W)	Loadloss (75"C)(W)	No-load current(%)	Impedance voltage(%)	Exteriorsize (Lxwxh)	Totalweight (kg)
30	6.3 6.6 10 0.5 1	+2x2.5	0.4	Dyn11 Yyn0 Yzn11	80	630/600	\|1.5	4	800x500x850	350
50					100	910/870	1.3		820x550x850	400
)3					110	1090/1040	1.2		835x580x850	430
30					130	1310/1250	1.2		840x600x880	450
100					150	1580/1500	1.1		860x600x890	490
125					170	1890/1800	1.1		1020x660x900	610
160					200	2310/2200	1		1035x660x950	670
200					240	2730/2600	1		1040x680x980	730
250					290	3200/3050	0.9		1140x740x1010	850
315					340	3830/3650	0.9		1160x760x1150	970
400					410	4520/4300	0.8		1230x800x1210	1130
500					480	5410/5150	0.8		1320x900x1210	1345
630				Dyn11 Yyn0	570	6200	0.6	4.5	1420x920x1230	1630
					700	7500	0.6		1480x1000x1285	1950
1000					830	10300	0.6		1600x1100x1330	2215
1250					970	12000	0.5		1655x1135x1375	2565
1600					1170	14500	0.5		1815x1260x1450	3100
2000					1550	18300	0.4		1920x1305x1510	3785
2500					1830	21200	0.4		2120x1430x1575	4570

110kv Series Oil Immersed Type Transformer, Frequency 50/60Hz , Copper Material

_{Note: 1, To transformers whose rated capacity of 500kVA and below,
load loss in the table above the diagonalis suitable for Dyn11 or
Yzn11 connection group,}

_{the load loss below the diagonal suitable for YynO connection
group.}

_{2, according to user needs, can provide transformer with high
voltage tap range}

_{3, according to user needs, can provide transformer with
low-voltage of 0.69kV .}

_{4, if the user needs, can also choose other loss values.}

_{5, due to the continuous update of the product, weight &size in
the table may changes.Most correct Dimension chart will be provied
when making order.}
