    XGN17-12 Medium Voltage Switchgear For Industrial Electrical Distribution

    Ask Lasest Price
    Brand Name : HENGFENGYOU
    Model Number : HXGN17
    Certification : ISO IEC CB COC KEMA SNI SABS CCC
    Price : 200-20000/piece
    Payment Terms : LC T/T
    Supply Ability : 5000 piece/year
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    XGN17-12 Medium Voltage Switchgear For Industrial Electrical Distribution

    XGN17-12 Electrical Medium Voltage MV HV Switchgear 3.6KV 7.2KV 11KV 12KV 630A,1000A,1250A,1600A, 2000A,2500A,3150A


    XGN17-12 medium voltage switchgear is mainly used as reception and distribution of power supply

    of 3.6- 12KV, 3 Phase AC, 50Hz indoor system.It is specially applied to cases where frequent operations

    are needed. The main switch applies ZN28A-12 segmental type vacuum circuit breaker with Cd10 electro

    magnetic operational mechanics, CT8/CT19A (B) spring operational mechanics, ZN28-12 series integral

    vacuum breaker (with CD17 Electromagnetic Operational mechanics, CT17/CT19 spring operational

    mechanics) or applies ZN63-12(VS1) vacuum circuit breaker. Isolation switch applies GN30-10 rotating

    style and GN22-10 high current isolation switch.


    Advantages

    1. This switchgear is case metal-enclosed structure. In accordance with the national standard GB3906 and

    international standardIEC298, protection degree IP2X. The metal-enclosed structure effectively prevents

    short-circuit failure by intruders .

    2. When air insulation distance between polar to polar or polar to ground ≤125mm, porcelain support insulators

    (≥8000N) is applied. All these ensure higher insulation intensity and stability.

    3. Breakers, both upper and lower insulation switches, grounding switches and interlock mechanisms between

    doors all takes force mechanical lock mode to meet the requirement of "five- prevention"
