    Customized Oil Immersed Distribution Transformer Re - Melting Furnace Transformer

    Ask Lasest Price
    Brand Name : HENGFENGYOU
    Model Number : 10kv
    Certification : ISO IEC CB COC KEMA SNI SABS CCC
    Payment Terms : LC T/T
    Supply Ability : 5000 pieces/year
    Delivery Time : 15 DAYS
    Price : 500-30000
    • Product Details
    • Company Profile

    Customized Oil Immersed Distribution Transformer Re - Melting Furnace Transformer

    10kv Oil Electro-Slag Re-Melting Furnace Transformer (HZDSPZ-1620/10)


    Product features

    1. Magnetic Core


    The three-limb iron core is made of oblique cut Grain-oriented, seven-step silicon steel

    lamination insulated on both sides, guaranteeing low losses and low noise. These values

    are even improved by laser treatment. It is protected on the surface with a flash-proof varnish

    in order to prevent the sheet from corrosion and to reduce the noise.


    2. The winding


    The winding as the center piece of the transformer must be especially protected - both against

    high electrical stress due to external over voltages and against mechanical overloads by short

    circuits.XINPOMING transformers are systematically designed to meet these requirements.

    The windings are made of copper or aluminum. Low-voltage windings are made of strip or flat

    wire, and the high voltage windings are manufactured from round or profile wire.

    ("diamond-dotted paper") bonds the winding into a compact block while drying and

    increases the short-circuit capacity additionally.


    Model N.O.Rated Capacity
    (KVA)
    Voltage CombinationConnection SymbolNo-Load Loss
    (W)
    Load Loss
    (W)
    No-Load Current
    (%)
    High Voltage
    (KV)
    Tapping range of high voltageLow Voltage
    (KV)
    10KV S9 Series106
    6.3
    6.6
    10
    10.5
    11
    +/-5%
    or
    +/-2*2.5%
    0.4Yyn0
    or
    Dyn11
    703002.4
    201005002.3
    301308002.1
    501708702.0
    6320010401.9
    8025012501.8
    10029016001.6
    12534018001.5
    16040022001.4
    20048026001.3
    25066030501.2
    31567036501.1
    40080043001.0
    50096061001.0
    630120062000.9
    800140075000.8
    10001700103000.7
    12501950120000.6
    16002400145000.6
    20002900175000.6

    Customized Oil Immersed Distribution Transformer Re - Melting Furnace Transformer


    Company profile

    Qingdao Hengfengyou Electrical Engineering Co. , Ltd. is one of the large-scale electric

    complete sets of manufacturers in China, specializing in oil-immersed transformers, dry-type

    transformers, high-voltage Cabinets, low-voltage cabinets and substation manufacturing specialized

    electrical enterprises. The company is located in the beautiful coastal city of china-qingdao.

    The company has a registered capital of 10 million yuan, 20 senior technical personnel, more than

    500 employees, and a sound sales and service system, annual output value of US $1 billion, the

    products sell well at home and abroad. For a long time, the company has maintained close technical

    exchanges with universities, research institutes and power enterprises at home and abroad, and has

    first introduced the world's most advanced electrical technology such as Germany, the United States

    and France, self-designed and developed SCB series dry-type transformer and SC series

    oil-immersed transformer, with high operating efficiency, energy-saving obvious, the overall performance

    index reached the world advanced level. The company also maintains a long-term strategic partnership

    with Schneider, ABB, Simmons, Zhengtai and other domestic and foreign suppliers of high-quality

    electrical components, absorbing advanced production experience of electrical equipment abroad,

    self-designed and developed a series of substation equipment, the realization of substation automation,

    intelligence, product operation quality has been highly recognized by the owners at home and abroad.


    Customized Oil Immersed Distribution Transformer Re - Melting Furnace Transformer


    Our Service:

    1. quick response in before sales period help you got order.
    2. excellent service in production time let you know each step we made.
    3. reliable quality solve you after sale headache.
    4. long period quality warranty ensure you can buy without hesitate.
