General info
MNS is modularized, multi-functional low voltage distribution
switchgear, which is applicable to metallurgy, petroleum, chemicaL
Advantages
1. Panel board with compact structure, save the volume of cabinet
body.
2. The panel board can be arranged back to back
3. The panel board body can meet the requirements of earthquake
resistance, oscillation resistance and shock resistance
4. It can be built up into different modes freely, such as fixed
type and draw-out type
5. Corresponding protection class of the panel board body could be
designed according to the different requirements of the job and
environment.
6. Select and using standard component entirely, convenient for the
design of project planner.
7. The arrangement of power distribution circuit is economic
8. With anti electric arc design
9. Convenient for equipment upgrade and inprovement
10. The panel board is free of maintenance to the most extent.
11. Safe for the opeartion
12. Reliable enough and high flexibility.
Parameters
Rated voltage 380V
Rated power current 100~4000A
Rated short time withstand current 65kA
Rated peak withstand current 136kA
Drawing
Structural Characteristics:
1. Compact design:
2. High commonality of the structure and flexibility of assembling.
The cubicle body is made up of C-type material with modulus 25mm,
it meets the requirements of different structural types, protection
categories and operation environment.
3. Modular design: different modular units form standard units of
protection, operation, transformation, control, regulation,
measurement or indication. Users can freely choose them to assemble
what they want. More than 200 assembly components can form
different projects of frame configurations and drawer units.
4. Safety: using lots of plastic components of high strength
preventing-burning to increase safety.
5. High technology: main parameters reach international technology
level.
6. Smaller space: Higher level of miniaturization, smaller space to
store and transport pre-manufactured components.
7. Easy to be assembled, no need of special complicated tools.
Details
Service conditions
◎ Ambient airtemperature should be within -5°C~+40°C, average
temperature within 24h should not exceed +35°C.
◎ Atmospheric conditions: air should be clean. Relative humidity
should not exceed 50% at +40°C, higher relative humidity is allowed
at lower temperature condition, for instance, 90% at +20°C, please
take measures for the dew produced on the product caused by
temperature change occasionally.
◎ Altitude: not exceed 2000m.
◎ Ambient temperature for storage and transportation: -25°C~+55°C,
short time (usually not beyond 24h) highest temperature not exceed
70°C. The product should not be subject to any irreversible damage
underthe extreme temperature and should be able to work normally
underthe normal conditions.
ATTENTION:
1.The payment term: We accept TT,30% deposit and 70% balance
against copy of BL.
2.The delivery time: Usually it will take about 15-20 days.
3.The standard of package: Usually use strong plywood case for
protection.
4.The logo: If you have good quantity, it absolute no problem to do
OEM.
5.Our market: our products are popular in Indonesia, Philippines,
Russia, USA, Middle East and so on. Some of them are our regular
customers and some of them are developing. We hope you can join us
and make mutual benefit from our cooperation..
6.Warranty: in 12 month since BL date.
order instruction:
1. Schematic diagram of main circuit or electrical schematic
diagram
2. Arrangement and layout
3. Model, specification and quantity of main components.
4. Incoming and outgoing wire method and cable specification, etc
5. If bus connection is required between the devices, bus
connection and height from the ground shall be provided.
6. Other ordering requirements
