4000kva 20kv 10/0.4kv 6/0.4kv dry type transformers power
distribution electrical dry transformer
This kind is SG(B)10 H-class insulated dry-type power transformer.
Our transformer is equipped characters as low loss, low noise,
strong protection for thunder and lighting, well anti-shortcut
capacity and fine appearance etc. It combines advanced equipments
and manufacturing process, and it has four remote functions: remote
communication, remote test, remote adjustment and remote control.
By remote control from a computer, the power station could be work
without any works on watch on the night. All our transformer has
passed the test by National Mechanical & Industrial Bureau and
National Power Company. The transformer is mainly used in power
network, and the projects of power distribution. electricity
transformer
Core equipped with advanced three steps: vertical and horizontal
and horizontal cut, lap and multi-stage. It disperses the air
distribution, improve the magnetic path. Decrease the no load loss,
no load current and noise. electricity transformer
Core adopts series measures dragged panel, pressed the coil,
particular glue for silicon steel to increase the strength of
mechanism. Power grid electric transformer
New structure of high and low voltage winding, reasonable
arrangement for oil tube and connection which increasing the
capacity of mechanical strength and anti-shortcut.
The tank is bell type or core suspension type, the wall of tank is
as wave form.
The advantage is as follows:
1. Strong thermal shock resistance, large overload capacity;
2. High flame retardant, high fire resistance;
3. Low loss, low partial discharge, low noise;
4. No harmful gases, no pollution to the environment;
5. It is not sensitive to humidity and dust, small in size, no
cracking;
6. Easy to maintain.
Applicable location:
It is most suitable for use in harsh environments with high fire
protection requirements, high load fluctuations, and dirty and wet
conditions.
Such as airports, power plants, metallurgical operations,
hospitals, high-rise buildings, shopping centers, residential areas
and petroleum, chemical, nuclear power plants, nuclear submarines
and other special environments.
| Model | SCB10-500/10 | Capacity | 500 KVA |
| Primary Voltage | 10KV , 11KV | Secondary Voltage | 0.4 KV |
| Rated current(H.V.) | 28.87A | Rated current (L.V.) | 721.7 A |
| Vector Group | DYN11 | Insulation & Heatproof Class | F |
| Max.temperature rising | 100K | Short-circuit impedance | 4.10 % |
| phase | 3 | Frequency | 50Hz |
| Cooling Method | AN / AF | Net Weight | 1810Kgs |
| Place of Origin: | Hubei, China (Mainland) | Usage: | Power |
| Brand Name: | Ximai | Phase: | Three |
| Model Number: | SGB10 | Coil Structure: | Toroidal |
| Type: | Dry type transformer | Frequency: | 50/60Hz |
| Rated capacity: | 400KVA | Connection symbol: | Yyn0 / Dyn11 |
| Input Voltage: | 6kv/6.3kv/10kv/10.5kv/11kv | Output Voltage: | 0.4kv |
| Certification: | ISO, WSC, CTQC | | |
| Standard: | GB6450-1986; GB/T10228-2008; GB/T17211-1998; GB/1094.3-2003;
JB/T10008-2004; JB/T56009-1998 |
Note: due to the constantly updated products, shape size and
product weight in the table will have some changes, please refer to
provide the appearance size chart when ordering.
ATTENTION:
1. The payment term: We accept TT,30% deposit and Pay 70% before
shipment.
2. The delivery time: Usually it will take about 15-20 days.
Note: due to the constantly updated products, shape size and
product weight in the table will have some changes, please refer to
provide the appearance size chart when ordering.
3. The standard of package: Usually use strong wood case for
protection.
OUR SERVICE:
1. quick response in before sales period help you got order.
2. excellent service in production time let you know each step we
made.
3. reliable quality solve you after sale headache.
4. long period quality warranty ensure you can buy without
hesitate.
